Used Lister CS4 / Ford 2722E 72HP Marine Diesel Engine
Description
Used Lister CS4 FORD 2722E 72HP Marine Diesel Engine
Used Lister Petter CS4 72hp Four Cylinder Heat Exchanger Cooled Marine Diesel Engine Complete With PRM 2:1 Ratio Hydraulic Gearbox. Year Of Build 1992. Marinised by Lister Petter but are essentially based on the very solid Ford 2722E industrial engine. We have a selection of these units available, all direct from the Ministry Of Defence due to replacement with more powerful units. All units start instantly with no excessive smoke, leaks, funny noises etc. All fluids are clean and in the right places. These engines are currently running 24V electrics but for an additional cost we can replace the starters and alternators with 12V units if required. Very solid engines with a great reputation among private and commercial operators alike.
Manufacturer: Lister Marine
Year built: 1992
Power: 72
Motor: 53
Fuel: Diesel
Used Lister CS4 / Ford 2722E 72HP Specs
| Brand | Ford / Lister CS4 Marine Conversion |
| Full Model Code | Ford 2722E (Lister CS4 Package) |
| Country of Origin | United Kingdom |
| Engine Family/Series | Ford Dover Series Base / Lister Marine Marine Build |
| Engine Type & Configuration | Inline 4-Cylinder, 4-Stroke, Vertical Marine Diesel |
| Aspiration & Induction System | Naturally Aspirated, Direct Injection |
| Displacement | 4.150 Liters / 4150 cc |
| Bore x Stroke | 107.0 mm x 115.0 mm |
| Cylinder Count & Valves per Cylinder | 4-Cylinder, 2-Valves per Cylinder (8 Valves Total) |
| Compression Ratio | 16.5:1 |
| Rated Power / Horsepower | 72 HP (53.7 kW) @ 2500 RPM |
| Maximum Engine Speed / Rated RPM | 2600 RPM |
| Maximum Torque | 235 Nm @ 1600 RPM |
| Fuel System & Injection Type] | Mechanical Simms-Minimec In-line Fuel Injection Pump |
| Governor Type | Mechanical Centrifugal Governor |
| Electrical System Voltage & Alternator Output | 12V System, 60 Amp Marine Alternator |
| Starting System | 12V Heavy Duty Electric Starter Motor |
| Cooling System Type | Freshwater Cooling Loop with Heavy-Duty Raw Water Heat Exchanger |
| Lubricating Oil Capacity / Oil Pan Capacity | 10.5 Liters |
| Exhaust Diameter / Exhaust System Type | 63 mm / Water-Cooled Marine Wet Exhaust Elbow |
| Flywheel & Flywheel Housing Size | SAE 3 Flywheel Housing Configuration |
| Dry Weight without Marine Gear | 415 kg (915 lbs) |
| Dimensions L x W x H | 935 mm x 620 mm x 780 mm |
| Emission Certifications & Duty Rating | Pre-Emission Standard Era / Continuous Duty Heavy Commercial & Pleasure |
| Application | Displacement motor cruisers, traditional heavy timber fishing boats, work launches, and small tugs (Typical hull lengths 32-42 feet, traditional shaft drive alignment). |
