Used Bukh DV36 36HP Marine Diesel Engine
Description
Used Bukh DV36 36HP Marine Diesel Engine
Used Bukh DV36 36hp Three Cylinder Heat Exchanger Cooled Marine Diesel Engine Package Including Gearbox, Control Panel & Loom. We have a selection of these units available, all removed from ships lifeboats and as such all have run less than 250hrs from new and been very well maintained. In many cases these engines will have run less than 100hrs from new!! They have also been running on closed circuit cooling so have never even tasted salt water. They have been converted back to the more common sea water heat exchanger cooling system in our UK workshops using new original parts. They have all been test run in our workshops, serviced, cleaned, primed and resprayed in Bukh red and are ready to go to work.
Manufacturer: Bukh
Year built: 1994
Starter: Electric start
Cooling type: Salt water
No. of previous owners: 1
Power: 36
Motor: 27
Fuel: Diesel
Used Bukh DV36 36HP Marine Diesel Engine Specs
| Brand | Bukh |
| Full Model Code | DV36 ME |
| Country of Origin | Denmark |
| Engine Family/Series | DV Heavy-Duty 3-Cylinder Series |
| Engine Type & Configuration | Inline 3-Cylinder, 4-Stroke, Vertical Marine Diesel |
| Aspiration & Induction System | Naturally Aspirated, Direct Injection with Rotating Mass Counter-Balancing System |
| Displacement | 1.447 Liters / 1447 cc |
| Bore x Stroke | 85.0 mm x 85.0 mm |
| Cylinder Count & Valves per Cylinder | 3-Cylinder, 2-Valves per Cylinder (6 Valves Total) |
| Compression Ratio | 18.5:1 |
| Rated Power / Horsepower | 36 HP (26.5 kW) @ 3600 RPM |
| Maximum Engine Speed / Rated RPM | 3600 RPM |
| Maximum Torque | 90 Nm @ 1800 RPM |
| Fuel System & Injection Type] | Bosch Direct Injection Pump with Individual Fuel Injectors |
| Governor Type | Mechanical Centrifugal Governor |
| Electrical System Voltage & Alternator Output | 14V, 50 Amp (700W) Alternator with Isolation Diodes |
| Starting System | 12V Heavy Duty Electric Starter with Manual Decompression Hand-Crank Option |
| Cooling System Type | Thermostatically Controlled Seawater Raw Water Cooled or Heat Exchanger Configuration |
| Lubricating Oil Capacity / Oil Pan Capacity | 5.5 Liters |
| Exhaust Diameter / Exhaust System Type | 50 mm / Water-Injected Wet Exhaust Elbow |
| Flywheel & Flywheel Housing Size | Open Flywheel Design with Heavy Rim / Custom Bukh Pattern |
| Dry Weight without Marine Gear | 265 kg (584 lbs) |
| Dimensions L x W x H | 815 mm x 490 mm x 620 mm |
| Emission Certifications & Duty Rating | SOLAS Approved, Pre-Tier Emission Controls / Heavy Continuous Commercial Duty |
| Application | Displacement motor sailors, commercial workboats, lifeboats, and heavy displacement pleasure yachts (Typical hull lengths 28-36 feet, traditional shaft drive alignment). |
