Phasor JD4-65.0kW Marine Diesel Generator (1800 RPM)
$7,938.00
In Stock
Used Phasor JD4-65.0kW Marine Diesel Generator (1800 RPM) Specs
| Brand / Manufacturer | Phasor Marine Power Systems |
| Full Model Code | JD4-65.0 kW (Standard Heat Exchanger Cooled) |
| Generator Type | Stationary Single/Three-Phase Marine Diesel Generator Set |
| Prime Power Output | 65.0 kW (65,000 Continuous Watts) |
| AC Voltage Options | 120/240V Single Phase | 120/208V, 277/480V Three-Phase Configurations @ 60 Hz |
| Engine Architecture | John Deere 4045 Series, 4-Cylinder, 4-Stroke Marine Diesel Engine (4.5L Displacement) |
| Engine Operational Speed | Static 1,800 RPM (Low-Speed Synchronous Industrial Design) |
| Cooling System Type | Cupro-Nickel Heat Exchanger Cooled with Water-Cooled Exhaust Manifold Grid |
| Injection & Governor | Direct Injection Fuel System with Isochronous Electronic Governor Control Matrix |
| Starting System | 12V DC Electric Starter Motor with Dedicated Engine Grounding Harness |
| Alternator Regulation | Brushless Synchronous Exciter End with Solid-State Automatic Voltage Regulator (AVR) (±1% Accuracy) |
| Safety Management Systems | Safety Shutdown Modules for Low Lubricating Oil Pressure and Excessive Coolant Temperature |
| Chassis & Structural Mount | Rigid Welded Steel Mounting Rail Base with Multi-Point Heavy Elastomeric Vibration Isolators |
| Net Weight | Approx. 748 kg (1,650 lbs) Base Dry Weight Class |
| Dimensions L x W x H | 1397 mm x 711 mm x 914 mm (55.0" x 28.0" x 36.0") |
| Ideal Application | Excellent primary or auxiliary power tracking for mid-sized commercial workboats, luxury charters, and coastal tugs operating high-load galley, winch, and multi-zone HVAC grids. |
