Phasor JD4-80.0kW Marine Diesel Generator (1800 RPM)
$9,990.00
In Stock
Used Phasor JD4-80.0kW Marine Diesel Generator (1800 RPM) Specs
| Brand / Manufacturer | Phasor Marine Power Systems |
| Full Model Code | JD4-80.0 kW Premium Marine Series |
| Generator Type | Stationary Single/Three-Phase Marine Diesel Generator Set |
| Prime Power Output | 80.0 kW (80,000 Continuous Watts) |
| AC Voltage Options | 120/240V Single Phase | 120/208V, 277/480V Balanced Three-Phase Core @ 60 Hz |
| Engine Architecture | John Deere 4045T Turbocharged 4-Cylinder Heavy-Duty Marine Diesel Engine (4.5L Platform) |
| Engine Operational Speed | Static 1,800 RPM (Low Mechanical Stress Design Line) |
| Cooling System Type | Closed-Loop Cupro-Nickel Heat Exchanger with Seawater Auxiliary Pump Module |
| Fuel System Layout | Mechanical Injection with Electronic Governor Control (Provides clean electrical frequency response) |
| Starting System | 12V DC Electric Starter with 12V High-Output Battery Charging Alternator Unit |
| Alternator Regulation | Stamford/Newage Industrial Brushless Generator Core with Automatic Voltage Regulation (AVR) |
| Safety Management Systems | Automated Engine Safety Interruption Shield (High Temperature / Low Oil Pressure Overrides) |
| Chassis & Structural Mount | Heavy Structural Steel Platform Base with Heavy-Duty Elastic Anti-Vibration Pads |
| Net Weight | Approx. 839 kg (1,850 lbs) Base Dry Weight Class |
| Dimensions L x W x H | 1448 mm x 736 mm x 965 mm (57.0" x 29.0" x 38.0") |
| Ideal Application | Continuous duty commercial vessel deployment, yacht utility arrays, and secondary processing stations demanding absolute electrical stabilization. |
