Scag V-Ride II 36in 19HP Kawasaki Stand-On Mower – Commercial
No guesswork, Scag V-Ride II sends 19 horsepower to the deck. A 36-inch deck backs it up, and a Kawasaki engine drives it. Commercial-grade construction holds up to daily route use.
- Rated for 19 horsepower on demand
- Cuts a wide 36-inch swath
- Commercial-grade parts built for daily runs
- A Kawasaki engine powers every pass
- Runs as a true stand-on mower
Description
Cutting through narrow backyard gates, the Scag V-Ride II 36in 19HP Kawasaki commercial stand-on mower powers into restricted residential properties without sacrificing commercial deck stamina. Landscape maintenance contractors waste valuable labor minutes pushing walk-behind mowers through 36-inch gates on gated commercial accounts. This 36-inch stand-on commercial machine combines an Advantage fabricated 7-gauge steel deck with dual hydraulic pumps, high-torque Parker wheel motors, and a commercial 19HP Kawasaki FX600V engine that slices through dense grass at forward speeds up to 8.5 MPH.
Dual hydraulic drive pumps and Parker wheel motors provide positive ground control, tracking straight along property perimeters and pivoting around tight landscaping borders. The 36-inch Advantage cutting deck features heavy cast-iron greaseable spindles and reinforced bullnose edges that withstand concrete curb scrapes and fence post collisions. An isolated operator suspension platform absorbs terrain shocks to protect crew knees and lower backs during all-day commercial cutting shifts.
Key Engineering Features of Scag V-Ride II 36in
- 36-Inch Advantage 7-Gauge Steel Deck: Delivers heavy plate steel construction with reinforced leading edges to survive daily commercial abuse.
- 19HP Kawasaki FX600V Commercial Engine: Supplies reliable combustion displacement to power through thick grass without RPM fade.
- Dual Hydraulic Pumps & Parker Wheel Motors: Delivers smooth, responsive stand-on steering control up to 8.5 MPH forward transport speed.
- Coil-Spring Operator Suspension Platform: Cushions the operator with heavy springs and elastomeric bumpers to eliminate fatigue over rough ground.
- Scag Heavy-Duty Cast-Iron Spindles: Houses precision tapered roller bearings to withstand blade impact shocks from hidden yard obstacles.
- Compact 36-Inch Gate-Access Profile: Clears standard 38-inch residential privacy gates with the discharge chute upright.
Field Durability & Operational Economy
Built for high-density residential routes, this compact commercial stand-on mower turns manual push-mower accounts into fast riding jobs.
- Narrow 36-inch deck width glides through standard backyard gates, eliminating manual push-mower labor on commercial routes.
- A massive 7-gauge steel deck shell withstands direct impacts with rocks and concrete curbs without bending or throwing blades out of alignment.
- Compact stand-on chassis allows rapid dismounts to clear yard debris, cutting total property service time.
Equipment Fitment & Repower Applications
Weighing 825 pounds dry with an operating width of 38 inches with the chute raised, this 36-inch machine clears tight gated acreage fast and packs tightly on commercial landscape trailers alongside wide-area mowers.
Warranty Coverage & Field Maintenance
- Commercial fleet operators receive 2-Year limited commercial warranty coverage against structural, deck, and hydraulic defects.
- The commercial Kawasaki engine receives full 3-Year manufacturer warranty backing through authorized dealer service centers nationwide.
Change engine oil after the initial 20 operating hours, then service every 100 hours with SAE 30 or 10W-30 motor oil. Inspect the air filter weekly on dry grading sites, and maintain spark plug gaps at 0.030 inches. Order the Scag V-Ride II 36in 19HP Kawasaki commercial stand-on mower from Mulmotor.com for guaranteed factory-fresh units, complete manufacturer warranty coverage, and dedicated commercial equipment support.
Scag V-Ride II 36" Stand-On (19HP Kawasaki) Specs
| Technical Parameter | Official Specification |
|---|---|
| Brand & Series | Scag V-Ride II Series |
| Full SKU/Model | SVRII-36A-19FX (Kawasaki FX600V) |
| Country of Origin | USA |
| Engine Brand & Model | Kawasaki FX600V (Commercial Grade) |
| Displacement (cc) | 603 cc |
| Horsepower/Torque | 19 HP at 3600 RPM |
| Fuel Capacity (Gallons/L) | 5.0 Gallons (18.9 L) |
| Oil Capacity & Recommended Grade | 1.8 qt (1.7 L) / SAE 10W-40 |
| Oil Filter OEM Part Number | Scag 486221 / Kawasaki 49065-7007 |
| Spark Plug Type & Gap | NGK BPR4ES / 0.030" |
| Air Filter Type | Heavy-Duty Canister Air Filter |
| Starting System | Electric Start |
| Transmission Model | Dual Hydro-Gear 10cc Pumps / Parker Wheel Motors |
| Transmission Oil Type | Scag 20W-50 Specialty Hydraulic Oil |
| Max Forward Speed (mph/kmh) | 8.5 mph (13.7 km/h) |
| Max Reverse Speed (mph/kmh) | 4.5 mph (7.2 km/h) |
| Cutting Width (Inches) | 36 Inches |
| Deck Construction (Gauge & Type) | Advantage™ 7-Gauge Fabricated Steel |
| Cutting Height Range | 1.5" - 4.5" |
| Height Adjustment Positions | Manual Pin Adjust (1/4" increments) |
| Number of Blades | 2 Blades (Marbain® Steel) |
| Blade Tip Speed (fpm) | 18,500 fpm |
| Blade Bolt Torque (ft-lbs) | 75 ft-lbs |
| Spindle Housing Material | Heavy-Duty Cast-Iron |
| Front Tire Size | 11 x 4-5 (Flat-Free) |
| Rear Tire Size | 20 x 8-10 |
| Seat Type & Suspension | Extra-Thick Operator Pad w/ Coil Suspension |
| Dry Weight (lbs/kg) | 735 lbs (333 kg) |
| Commercial/Residential Warranty | 2-Year Commercial / 3-Year or 500-Hour Non-Comm |
| SEO Usage Profile (Terrain & Max Acreage) | Professional Commercial; Compact Properties; Up to 3 Acres |
