VEGE Remanufactured 324B 2.4L 2389cc Premium Grade Long Block Engine

Description

Does your commercial service truck need exceptional four-cylinder pulling durability? The VEGE Remanufactured 324B Premium Long Block Engine repowers high-demand fleet transport vehicles. This 2.4L 2389cc inline-4 premium grade long block outputs 150HP with balanced rotating assemblies and tight machining tolerances. Stiff dual overhead camshaft springs require initial lubrication priming before engine startup.

Pearlitic ASTM gray iron casting gives the VEGE 324B long block assembly maximum structural damping and fatigue resistance under continuous urban haul cycles. The 5-main bearing bottom end secures a precision balanced forged steel crankshaft. Engineered for 12V electrical systems, starter current draws 160A. Net dry weight lands at 325 lbs within a mounting stance of 26in length by 23in width and 27in height. Oil pan capacity holds 4.8 quarts.

Key Features of VEGE Remanufactured 324B

Commercial transport operators buy VEGE Remanufactured 324B engines to execute a premium commercial long block repower on service vans requiring high uptime and low vibration. This VEGE remanufactured long block sets exceptional durability standards for demanding commercial fleet operators.

• Precision balanced crankshaft reduces rotational vibration through the entire 5,600 RPM range.
• Diamond-turned hypereutectic pistons feature moly-coated skirts for reduced cold start bore scuffing.
• Induction-hardened stellite valve seats withstand continuous high-temperature commercial highway hauling.
• Dual overhead camshaft profiles maximize low-end torque output between 1,800 RPM and 3,600 RPM.
• Precision double roller timing chain eliminates timing deflection under severe torque shock loads.
• High capacity oil pump supplies 50 PSI continuous pressure to main bearings and lifters.
• Precision machined bellhousing flange allows this 324B premium core to bolt to commercial gearboxes.

Brake Dynamometer Load Diagnostics

Brake dynamometer trials establish this 324B long block engine generates 150HP at 5,400 RPM and 160 ft-lbs torque output at 3,600 RPM on standard commercial fuels. Oil pressure holds 50 PSI at operating temperature while coolant flow keeps operating temperatures at 182°F. Pyrometer gauges confirm exhaust manifold heat within 1,180°F during full load step tests. Compression measurements verify 170 PSI across all 4 cylinders within 2% deviation. Crankshaft journal runout checks below 0.0003in TIR on dial indicators.

Engine Bay Operator Limits

Throttle lever pull force requires 5 lbs to overcome dual throttle return springs. Do not install this premium grade inline-4 long block engine in passenger cars lacking 26in longitudinal bay clearance or vehicles lacking 12V electrical systems. Fleet maintenance teams must check transmission bellhousing dowel alignment to prevent input shaft pilot bushing binding on this 324B engine core.

• Renew 5W-30 synthetic blend oil and filter every 250 operating hours or 4,000 miles.
• Inspect valve train cam lobes and timing chain guide wear every 800 run hours.
• Verify intake manifold torque at 22 ft-lbs every 400 operating hours.

Verified Crate Manifest Warranty

VEGE protects this premium long block with a 3-Year or 100,000-mile commercial powertrain warranty. The wooden freight crate contains the remanufactured 324B long block core, premium valve covers, oil pan, front timing cover, oil pickup tube, basic gasket set, and certified build inspection sheet.
