Taco 138D Series 100 Stainless Steel Pump 1HP 115v
$3,965.00
In Stock
Taco 138D Stainless Steel Pump Specs
| Technical Parameter | Official Specification |
|---|---|
| Brand & Series | Taco Comfort Solutions - 130 Series |
| Model Number/SKU | 138D (Stainless Steel) |
| Country of Origin | USA |
| Pump Type | Three-Piece In-Line Circulator |
| Horsepower (HP) | 1 HP |
| Voltage (V) & Phase (PH) | 115V / 1 PH / 60Hz |
| Amperage (FLA) | 13.4A |
| Motor RPM | 1725 RPM |
| Motor Type | Open Drip Proof (ODP) / Oil-Lubricated |
| Connection Type | 2-Bolt Universal Flange |
| Connection Size (Inches) | 3/4", 1", 1-1/4", 1-1/2" |
| Body Material (Casing) | Stainless Steel |
| Impeller Material | Non-Metallic Polymer |
| Shaft Material | Alloy Steel (Hardened) |
| Mechanical Seal Type | Two-Piece Carbon/Ceramic |
| Max Flow Rate (GPM) | 145 GPM |
| Max Head (Feet) | 48 Feet |
| Max Operating Pressure (PSI) | 125 PSI |
| Max Fluid Temperature (°F/°C) | 240°F (115°C) |
| Min Fluid Temperature (°F/°C) | 40°F (4°C) |
| Drive Type | Direct Drive (Spring Coupled) |
| Bearing Type | Sleeve Bearings (Babbitt Lined) |
| Flange-to-Flange Length | 8-1/2 Inches |
| Shut-off Head | 50 Feet |
| Thermal Protection | Automatic Reset Overload |
| Service Factor | 1.15 |
| Dry Weight (lbs/kg) | 42.0 lbs (19.1 kg) |
| Application Suitability | High-Flow Potable Water Recirculation |
| Compliance | NSF/ANSI 372 / UL / CSA |
| SEO Usage Profile | Industrial Potable Water / Large Open Loops |
