Taco 122N Series 100 Stainless Steel Circulating Pump 1/4HP 115V

Reduce connection changes on potable-water systems with Taco 122N Series 100 stainless steel circulating pump. Its 1/4 HP, 115-volt single-phase motor runs at 1,725 RPM and delivers up to 62 GPM with 29 feet of head. The universal two-bolt flange accepts 3/4-inch through 1-1/2-inch connections. Confirm the selected flange, water compatibility, and system curve before installation.

The Taco 122N uses a stainless steel casing, non-metallic polymer impeller, hardened alloy-steel shaft, and two-piece carbon/ceramic seal. Its ODP motor is oil-lubricated and uses a spring-coupled direct-drive arrangement with Babbitt-lined sleeve bearings. Automatic reset overload protects the motor. The supplied data also lists 125 psi maximum pressure, 240°F maximum fluid temperature, 8-1/2-inch length, 24 pounds dry weight, and 30 feet of shut-off head.

Key Features & Benefits

• 1/4 HP Motor: Fits potable-water and domestic hot-water recirculation systems.
• 115-Volt Single-Phase Service: Matches common electrical service after field verification.
• 62 GPM Maximum Flow: Provides a stated capacity reference for open-loop selection.
• 29 Feet Maximum Head: Helps compare piping resistance and elevation requirements.
• Universal Two-Bolt Flange: Accepts listed 3/4-inch through 1-1/2-inch connection sizes.
• Stainless Steel Casing: Provides the specified body material for potable-water service.
• Automatic Reset Overload: Provides listed motor protection.
• 24-Pound Dry Weight: Assists handling and support planning.

Why Choose Taco 122N

The Taco 122N combines stainless steel construction, universal flange sizing, and moderate head capacity in a compact Series 100 arrangement. It suits potable-water systems where connection flexibility matters.

• Build: Stainless steel, polymer, hardened alloy steel, and carbon/ceramic components define the assembly.
• Value: Universal flange sizing can reduce connection modifications during replacement.
• Audience: Fits plumbing contractors, residential service technicians, hotel maintenance teams, and facility operators.

Applications & Use Cases

Use this pump in potable-water systems within the listed 62 GPM and 29-foot limits. Check the selected flange size, 8-1/2-inch length, 24-pound handling requirement, oiling access, pipe supports, and fluid range. Keep pressure below 125 psi and temperature between 40°F and 240°F.

Warranty & Support

• Warranty Terms: Warranty duration and coverage for this Series 100 configuration require confirmation from the authorized seller.
• Service Requirements: Confirm coverage for seals, lubrication-related issues, installation conditions, and claim procedures.
• Model Verification: Match Taco 122N, 1/4 HP, 115-volt configuration, and SKU 122N to the order.

Verify 115-volt service, isolate the water line, inspect the seal, check oil condition, purge air, and check for leaks after startup. Select from the actual pump curve. Order the Taco 122N Series 100 stainless steel circulating pump from Mulmotor.com for authentic equipment, applicable warranty protection, and technical pump support.
