Bell & Gossett e-1532 4AD Centrifugal Pump 2HP 1750RPM 3-Phase ODP

Description

Move high-volume cooling water with Bell & Gossett e-1532 4AD 2 HP, a close-coupled footless pump with 5-inch suction and 4-inch discharge connections. Its 1750 RPM operating speed and 9.5-inch nominal impeller suit cooling towers and low-head circulation where large ports help limit piping restriction. Confirm the final impeller trim, electrical data, and pipe-support arrangement before installation.

The footless design places the pump within the connected piping, so proper support and alignment are essential. The supplied data does not state voltage, phase, amp draw, flow, head, pressure, dimensions, weight, or seal material. Verify the 4AD pump curve, suction conditions, phase rotation, and service clearance before startup.

Key Features & Benefits

• 2 HP Motor: Supports high-volume, low-head circulation in compatible commercial systems.
• 1750 RPM Speed: Provides a four-pole operating reference for steady cooling-tower service.
• 5-Inch Suction: Accommodates the large inlet connection specified for the 4AD case.
• 4-Inch Discharge: Defines the outlet size for compatible cooling-water piping.
• 9.5-Inch Nominal Impeller: Identifies the listed rotating component for equipment comparison.
• ODP Motor Enclosure: Specifies the open drip proof motor style for suitable placement.
• Footless Construction: Requires proper pipe support and alignment through the connected piping.
• 4AD Case Size: Provides a defined pump configuration for replacement planning.

Why Choose Bell & Gossett e-1532 4AD 2 HP

The 4AD configuration combines large connections, 2 HP power, and footless close-coupled construction for cooling towers and low-head commercial circulation.

• Build: Footless construction, ODP motor, 4AD case, and large suction and discharge ports define the arrangement.
• Value: Large connections can support lower piping restriction when the system is correctly selected.
• Audience: Suited to cooling-tower contractors, commercial HVAC installers, facility engineers, and industrial maintenance teams.

Applications & Use Cases

Use Bell & Gossett e-1532 4AD 2 HP for cooling-tower transfer, high-volume low-head circulation, and compatible 5-inch by 4-inch piping. The supplied data does not provide overall dimensions, unit weight, base details, or port reach, so verify pipe support, lifting access, motor clearance, and service space before installation.

Warranty & Support

• Warranty Terms Require Confirmation: Verify duration, coverage, registration, exclusions, and authorized service requirements with the seller.
• Confirm the 4AD case, 2 HP motor, 1750 RPM speed, ODP enclosure, impeller, phase, and voltage before ordering.

Inspect suction and discharge piping, support the footless assembly, verify motor rotation, prime the pump, and purge air before startup. Purchase the Bell & Gossett e-1532 4AD 2 HP footless centrifugal pump through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
