Bell & Gossett 104458LF Ecocirc XL N 20-140 Stainless Steel Circulator

Description

Support institutional potable-water circulation with Bell & Gossett 104458LF ecocirc XL N 20-140, a stainless-steel ECM circulator for 208–230 V single-phase service. Its 140 GPM maximum flow and 20 feet maximum head suit hospital, hotel, and other large domestic hot-water systems where open-loop material selection matters. Confirm the system curve, control wiring, and potable-water temperature before installation.

The large-frame ECM motor uses an integrated drive and supports Modbus RTU and BACnet MS/TP communication. Manufacturer reference data identifies the 104458LF stainless-steel model as a 1/2 HP configuration with a 35 W to 470 W rated power range. The supplied listing does not state connection size, exact dimensions, or confirmed weight, so verify the current submittal before startup.

Key Features & Benefits

• 1/2 HP ECM Motor: Supports high-volume institutional potable-water circulation.
• 208–230 V Single-Phase: Fits compatible commercial service panels for easier electrical planning.
• 140 GPM Maximum Flow: Handles large domestic hot-water return requirements within the stated range.
• 20 Feet Maximum Head: Provides a clear reference for lower-head, high-volume systems.
• Stainless-Steel Body: Provides the specified casing material for open-loop potable-water service.
• Modbus RTU and BACnet MS/TP: Supports building-automation integration where compatible controls are installed.
• 35 W to 470 W Power Range: Helps review electrical demand across changing operating conditions.
• ecocirc XL N Design: Identifies the stainless-steel potable-water version of the XL circulator family.
• High-Volume DHW Application: Suits hospitals, hotels, and other large institutional water systems.

Why Choose Bell & Gossett 104458LF ecocirc XL N 20-140

The ecocirc XL N 20-140 combines stainless-steel construction, ECM control, and building-automation communication for large institutional potable-water circulation.

• Build: Stainless-steel body, ECM motor, integrated drive, and communication capability define the supplied configuration.
• Value: Adjustable electronic operation and control integration can simplify monitoring across large DHW systems.
• Audience: Suited to hospital engineers, hotel maintenance teams, plumbing contractors, and institutional facility operators.

Applications & Use Cases

Use Bell & Gossett 104458LF ecocirc XL N 20-140 for high-volume institutional potable water, hospital DHW, hotel circulation, and compatible 208–230 V systems. The supplied data does not provide exact dimensions, unit weight, connection size, or port-to-port reach, so verify flange layout, valve clearance, communication access, pipe support, and service space before installation.

Warranty & Support

• Warranty Terms Require Confirmation: Verify duration, coverage, registration, exclusions, and authorized service requirements with the seller.
• Match SKU 104458LF, ecocirc XL N 20-140 model, stainless-steel body, 208–230 V supply, and control requirements before ordering.

Flush the potable-water loop, purge air, verify the 208–230 V supply, and configure Modbus or BACnet communication where used. Monitor flow, head, temperature, vibration, leakage, and power draw during commissioning. Purchase the Bell & Gossett 104458LF ecocirc XL N 20-140 stainless-steel ECM circulator through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
