Bell & Gossett 104300 Ecocirc XL 20-35 Iron Body Circulator

Description

Commercial heating controls use Bell & Gossett 104300 Ecocirc XL 20-35 for closed-loop circulation with adjustable pump response. Its ECM motor delivers up to 35 GPM against 20 feet of head, while proportional-pressure, constant-pressure, and fixed-speed modes support changing system demand. Confirm the Modbus RTU and BACnet MS/TP readiness, fluid temperature range, and control wiring before startup.

The Ecocirc XL 20-35 uses a cast iron body with ECM motor technology and a listed operating range from 14°F to 230°F. Its communication interface supports compatible building-management connections, while verified data does not include voltage, phase, amp draw, RPM, seal type, connection size, dimensions, weight, thermal protection, or self-priming capability. Match the circulator to the closed-loop heating or cooling curve before installation.

Key Features of Bell & Gossett 104300 Ecocirc XL 20-35

• ECM motor supports high-efficiency commercial heating and cooling circulation.
• 35 GPM maximum flow suits compatible closed-loop hydronic systems.
• 20-foot maximum head supports small commercial heating and cooling loops.
• Proportional-pressure control adjusts output as system resistance changes.
• Constant-pressure control maintains selected pressure across changing system demand.
• Fixed-speed control provides stable output for compatible circulation applications.
• Modbus RTU and BACnet MS/TP readiness supports building-management integration.
• 14°F to 230°F operating range supports approved hydronic fluid conditions.
• Voltage, phase, amperage, RPM, seal, connections, dimensions, weight, protection, and warranty require confirmation.

Why Choose Bell & Gossett 104300 Ecocirc XL 20-35

This Bell & Gossett ECM circulator combines multiple control modes with building-management readiness for commercial hydronic systems.

• Build: Cast iron construction and ECM motor technology support compatible closed-loop heating and cooling.
• Value: Adjustable pressure and speed modes can reduce unnecessary pump output across changing system demand.
• Audience: Commercial HVAC contractors, building automation integrators, facility engineers, boiler technicians, and hydronic designers can specify this model.

Applications & Use Cases

Use the Bell & Gossett 104300 Ecocirc XL 20-35 for commercial heating, cooling loops, closed hydronics, and BMS-connected circulation. Physical dimensions, unit weight, and connection reach were not supplied, so verify pipe spacing, valve clearance, controller wiring, motor access, lifting room, and service clearance before installation.

Warranty & Support

• Warranty: Bell & Gossett general product terms provide one year from installation or 18 months from product date code, whichever occurs first.
• Verify control settings, purge trapped air, inspect the seal area, confirm flow direction, and test communication connections during commissioning.

Flush system strainers, review operating mode, monitor the cast iron body for leakage, and test BMS communication during scheduled service. Purchase the Bell & Gossett 104300 Ecocirc XL 20-35 ECM circulator from Mulmotor.com for authentic equipment, applicable factory warranty protection, and pump support.
