Kohler CH730 3201 Horizontal Engine
In Stock
US $1,033.00
In Stock
Description
Kohler CH730 3201 Horizontal Engine
The Kohler CH730 3201 is a 725cc, V-twin, air-cooled, 4-stroke, horizontal-shaft engine that delivers 23 horsepower. It is designed for heavy-duty commercial applications, such as lawn mowers, utility vehicles, and industrial equipment. The Kohler CH730 3201 Horizontal Engine provides robust 725cc V-Twin power, a top-tier choice in the commercial Command Pro CH Series. This engine delivers high, consistent torque, making it ideal for large generators, hydraulic pumps, and heavy-duty utility equipment.
The Kohler CH730 3201 features a full-pressure lubrication system and commercial-grade components for maximum durability and reliability under continuous heavy load. Trust this powerful Kohler horizontal engine for its superior performance, fuel efficiency, and the unwavering reliability required in critical industrial applications.
| BRAND | Kohler |
|---|---|
| MODEL NUMBER | CH730-3201 |
| WARRANTY | 3 Year Consumer & Commercial |
| SHIPPING WEIGHT | 107 |
| DISPLACEMENT | 725cc |
| STARTER TYPE | Electric |
| CRANKSHAFT ORIENTATION | Horizontal |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 1-1/8″ x 4″ |
| CRANKSHAFT DIAMETER | 1-1/8″ |
| CRANKSHAFT LENGTH | 4″ |
| CRANKSHAFT END TAPPED SIZE | 7/16 – 20 |
| CRANKSHAFT KEYWAY WIDTH | 1/4″ |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| CYLINDERS | 2 |
| CYLINDER BORE TYPE | Cast Iron |
| AIR CLEANER TYPE | Large Capacity Dual Element |
| FUEL PUMP | Yes |
| OIL COOLER | Yes |
| OIL CAPACITY | 60 |
| LOW OIL ALERT | No |
| LOW OIL SHUTDOWN | No |
| IGNITION SYSTEM | Electronic |
| CARBURETOR TYPE | High Performance Accelerator Pump |
| CHOKE CONTROL | Manual and Remote |
| BOLT CIRCLE | 5-5/8; 7-3/4 |
| PTO HEIGHT | 6 – 1/8 |
