Miller Trailblazer 325 Efi Welder/Generator W/Excel Power Battery Charge Wic 907798005
Miller Trailblazer 325 EFI features Excel Power and WIC, offering the ultimate in fuel efficiency and remote parameter control for professional fabrication.
- Engine/Motor: 25 HP Kohler EFI engine.
- Cutting Deck: Wireless Interface Control (WIC).
- Drive System: Excel Power at idle speed.
- Discharge: Integrated battery charge/jump starter.
- Terrain: Structural steel and repair.
$8,148.00
In Stock
Description
The MILLER Trailblazer 325 EFI is an advanced engine-driven welder/generator featuring Electronic Fuel Injection (EFI) for superior efficiency. The standout feature is the Excel Power technology for quiet full-power generation at idle, the Battery Charge/Jump Start utility, and the WIC (Wire Feeder Interface Control) for optimized wire welding. Choose this highly versatile MILLER EFI Welder/Generator for superior fuel economy, quiet operation, and full service-truck utility with professional wire welding capability.
- Brand: Miller
- Model: Trailblazer 325 EFI with Excel Power, Battery Charge, and WIC
- MPN: 907798005
- Processes: Stick (SMAW), MIG (GMAW), Flux-Cored (FCAW), DC TIG (GTAW)
- Engine: Kohler EFI Gasoline Engine, 23 HP, Twin-Cylinder
- Rated Welding Output: 325A @ 25V, 100% Duty Cycle
- Welding Output Range: 20 – 325 Amps
- Excel Power: 2400W Continuous Sine Wave at Idle
- Auxiliary Power Output: 12,000W Peak, 10,500W Continuous
- Battery Charge/Jump Start: Yes – Built-in Functionality
- Wireless Interface Control (WIC): Included
- Fuel Tank Capacity: 12 gallons (45.4 liters)
- Run Time: Up to 24 hours depending on load
- Start Type: Electric Start
- Cooling System: Air-Cooled
- Dimensions: 40.5 in L × 20 in W × 32.75 in H
- Weight: Approx. 498 lbs (226 kg)
- GTIN: 715959691104
- Warranty: 3-Year Miller True Blue Warranty
Miller Trailblazer 325 EFI w/ Charge & WIC Specs
| Technical Parameter | Official Specification |
|---|---|
| Brand & Model | Miller Trailblazer 325 EFI (Charge/Jump) |
| Full SKU/Model | 907798005 |
| Engine Brand | Kohler ECH730 (EFI Gas) |
| Welding Processes | Stick, TIG, MIG, FCAW |
| Rated Output | 325 A at 28 VDC, 100% Duty Cycle |
| Generator Power | 12,000 Watts (Peak) / 10,500 Watts (Continuous) |
| Noise Level | 73.5 dB at 23 ft (Full Load) |
| Technologies | WIC, Excel Power, Battery Charge/Jump, Auto-Speed |
| Start Type | Electric Start |
| Cooling System | Air-Cooled Engine |
| Net Weight | 460 lbs (209 kg) |
| Warranty | 3-Year Miller True Blue Warranty |
| Application Information | Fleet Service Trucks; Cold Weather Starting; Mobile Fleet Maintenance |
