Miller Dynasty 210 TIG Welder w/ CPS (Auto-Line 120-480V)
$3,882.00
In Stock
Description
The MILLER Dynasty 210 TIG Welder is a versatile, portable AC/DC TIG and Stick welder ideal for professional repair and fabrication. Featuring Auto-Line technology, it runs on any input power from 120V to 480V. This package includes CPS (Coolant Power Supply), making it ready for water-cooled TIG torch operation for extended high-amperage use. Choose this highly flexible MILLER Dynasty TIG Welder for superior arc control and portability.
- Brand: Miller
- Model: Dynasty 210 TIG Welder with CPS
- MPN: 907816001
- Welding Processes: TIG (GTAW), Stick (SMAW)
- Input Voltage: 120V–480V, 1-Phase or 3-Phase
- Amperage Range (TIG): 1–210 Amps
- Amperage Range (Stick): 20–175 Amps
- Duty Cycle (TIG): 60% @ 210A
- Duty Cycle (Stick): 30% @ 175A
- Weight: 50 lbs (22.7 kg)
- Dimensions: 13.6 in H × 7.1 in W × 17 in D
- Power Source: Auto-Line, Accepts 120V–480V
- CPS: Integrated Cooler Power Supply
- Waveforms: Sine, Square, Soft Square, Triangular
- AC Frequency Control: 20–400 Hz
- AC Balance Control: Yes (Adjustable)
- HF Start: Yes
- Pulsed TIG: Yes
- Applications: Fabrication, Aerospace, Automotive, Shipbuilding, Pipe Welding
- Digital Display: Yes with Menu Navigation
- Cooling Options: Air or Water (via CPS)
- Warranty: 3-Year Miller True Blue Warranty
Miller Dynasty 210 AC/DC TIG w/ CPS Specs
| Technical Parameter | Official Specification |
|---|---|
| Brand & Model | Miller Dynasty 210 |
| Full SKU/Model | 907816001 (Power Source with CPS) |
| Input Voltage | 120–480 V (Auto-Line™ Technology) |
| Welding Processes | AC/DC TIG (GTAW), Pulsed TIG, Stick (SMAW) |
| Rated Output | 210 A at 18 V, 60% Duty Cycle |
| Amperage Range | 1–210 A |
| Noise Level | Quiet Operation |
| Technologies | Blue Lightning™ HF, Auto-Line™, Pro-Set™ |
| Start Type | HF / Lift-Arc™ Start |
| Cooling System | Forced-Air (CPS ready for external cooler) |
| Net Weight | 47 lbs (21.3 kg) |
| Warranty | 3-Year Miller True Blue Warranty |
| Application Information | Aluminum Signage; Custom Automotive; Light Industrial Manufacturing |
