Lincoln Sae 300 Mp Kubota T4 Welder Generator K4090-1
Lincoln SAE 300 MP features a pure DC generator and Kubota power, providing the industry-standard arc for precision pipeline welding and construction.
- Engine/Motor: 24.7 HP Kubota Diesel engine.
- Cutting Deck: Pure DC generator technology.
- Drive System: Temperature-stabilized copper windings.
- Discharge: OCV control for pipe welding.
- Terrain: Oil and gas pipelines.
$16,170.00
In Stock
Description
The LINCOLN SAE 300 MP Kubota T4 Welder/Generator is a professional-grade, engine-driven DC stick welder known for its classic, exceptionally smooth arc, favored by pipeline and heavy construction welders. This model is powered by a Kubota Tier 4 (T4) compliant engine, ensuring the lowest emissions and environmental compliance. The MP (Multi-Process) version adds CV output for wire welding. Choose this traditional LINCOLN Diesel Welder for unparalleled arc quality and modern emissions standards on demanding job sites.
- Brand: Lincoln Electric
- Model: SAE-300 MP Kubota T4
- MPN: K4090-1
- Engine: Kubota D1503-M, Tier 4 Final, 4-Cylinder Diesel
- Engine Power: 24.8 HP @ 1,800 RPM
- Fuel Type: Diesel
- Fuel Tank Capacity: 17 gallons (64.3 liters)
- Welding Output: Up to 300 Amps DC
- Duty Cycle: 100% at 250 Amps
- Processes Supported: Stick (SMAW), CV (with optional module)
- Welding Range: 40 – 300 Amps
- Remote Capabilities: CrossLinc compatible (optional)
- Generator Output: 3,000 Watts Continuous @ 120/240V AC
- Enclosure: Stainless steel roof and side panels
- Alternator Type: Brushless, pure DC generator
- Operating Temperature: -20°C to +55°C (All-Climate)
- Dimensions: 66 in L × 24.6 in W × 40 in H
- Weight: Approx. 1,585 lbs (719 kg)
- Noise Level: Approx. 76 dB @ 23 ft
- GTIN: 015082681614
- Warranty: 3-Year Lincoln Electric Limited Warranty
Lincoln SAE-300 MP Kubota T4 Welder/Generator Specs
| Technical Parameter | Official Specification |
|---|---|
| Brand & Model | Lincoln SAE-300 MP (Kubota) |
| Full SKU/Model | K4090-1 |
| Engine Brand | Kubota® V1505 (24.7 HP @ 1800 RPM, Tier 4 Final) |
| Welding Processes | Stick, TIG, MIG, Flux-Cored, Gouging |
| Arc Control | Customizable Arc Modes (Pipe, Root, Fill, Cap) |
| Rated Output | 300 A at 32 V, 60% Duty Cycle | 250 A at 30 V, 100% |
| Generator Power | 3,000 Watts (Single Phase, 60 Hz) |
| Max Amperage | 350 A Range |
| Enclosure | Low-Profile Industrial Design |
| Net Weight | 1,438 lbs (652 kg) |
| Dimensions | 24" W x 37.1" H x 71.1" L |
| Warranty | 3-Year Lincoln Electric Warranty |
| SEO Usage Profile | Professional Pipeline Welding; Refinery; Oil & Gas Construction |
