Lincoln Ranger 305G Welder Generator K1726-5

Description

Lincoln Ranger 305G Welder Generator K1726-5 Specs

The LINCOLN Ranger 305G is a top-of-the-line, gas-powered engine-driven welder/generator offering excellent multi-process welding capabilities (Stick, TIG, MIG, Flux-Cored) and strong auxiliary power. Known for its quiet operation and smooth arc performance, the Ranger 305G is a staple for service trucks, maintenance fleets, and construction crews. Choose this reliable Lincoln Ranger 305G Welder/Generator for its superior multi-process welding capabilities and consistent job site power.

• Brand: Lincoln Electric
• Model: Ranger 305G
• MPN: K1726-5
• Engine Brand: Kohler
• Engine Model: CH730 OHV (2-cylinder)
• Engine Power: 23 HP at 3,600 RPM
• Fuel Type: Gasoline
• Fuel Tank Capacity: 12 gallons (45.4 liters)
• Welding Output: Up to 305 Amps @ 25V, 100% Duty Cycle
• Processes: Stick, TIG, MIG, Flux-Cored, Gouging (up to 3/16″)
• Generator Power: 10,500 Watts Peak, 9,000 Watts Continuous
• Chopper Technology: Yes – smooth arc and reduced spatter
• Receptacles: (2) 120V duplex, (1) 120/240V receptacle
• Dimensions: 42.3 in L × 21.5 in W × 36 in H
• Weight: Approx. 510 lbs (231 kg)
• Noise Level: 100.7 dB @ Rated Output
• GTIN: 015082568885
• Warranty: 3-Year Limited Warranty
