Kohler CH730 3208 Horizontal Engine

Kohler CH730-3208 horizontal 4-cycle OHV V-Twin Command Pro engine is 725cc and puts out 23.5 HP (maximum horsepower). This CH730 has a 1-7/16″ x 4.46″ crankshaft. It features a 12V electric solenoid shift starter and blower housing to accept fixed guard. This model replaces PA-68500, PA-CH730-0038 and PA-CH730-3038.

Maximize torque and power with the Kohler CH730 3208 Horizontal Engine, a high-performance 725cc V-Twin from the commercial Command Pro CH Series. This engine is ideal for large generators, hydraulic pumps, and heavy-duty industrial equipment, delivering robust, consistent output. The CH730 3208 features a full-pressure lubrication system and heavy-duty components for maximum durability and reliability under continuous heavy load. Trust this powerful Kohler horizontal engine for its superior performance, low vibration, and the unwavering reliability required for critical professional applications.

BRAND Kohler
MODEL NUMBER CH730-3208
WARRANTY 3 Year Consumer & Commercial
SHIPPING WEIGHT 107
DISPLACEMENT 725cc
STARTER TYPE Electric
CRANKSHAFT ORIENTATION Horizontal
CRANKSHAFT TYPE Straight
FUEL SYSTEM Gasoline
GEAR REDUCTION No
CRANKSHAFT DIMENSIONS 1-7/16″ x 4.46″
CRANKSHAFT DIAMETER 1-7/16″
CRANKSHAFT LENGTH 4.46″
CRANKSHAFT END TAPPED SIZE 5/8 -18
CRANKSHAFT KEYWAY WIDTH 3/8″
CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) Counterclockwise
CYLINDERS 2
CYLINDER BORE TYPE Cast Iron
AIR CLEANER TYPE Large Capacity Dual Element
FUEL PUMP Yes
OIL COOLER Yes
OIL CAPACITY 60
LOW OIL ALERT No
LOW OIL SHUTDOWN No
IGNITION SYSTEM Electronic
CARBURETOR TYPE High Performance Accelerator Pump
CHOKE CONTROL Remote
BOLT CIRCLE 5-5/8; 7-3/4
PTO HEIGHT 6 – 1/8
