Evinrude 225HP H225HWLF – G2 H.O. 20in Shaft
Evinrude 225HP H225HWLF incorporates a 20in Shaft and white G2 styling with iSteer DPS, providing a high-performance tender motor experience that masters low-speed docking and explosive top-end speed with V6 H.O. power.
- Model: Evinrude 225HP H225HWLF outboard motor.
- Engineering: 3.4L V6 E-TEC G2 H.O. design.
- Performance: White-edition iSteer DPS H.O. injection.
- Output: 133-Amp total / 50-Amp net alternator.
- Warranty: 5-year official BRP limited warranty.
Description
Evinrude 225HP H225HWLF White H.O. iSteer DPS
Leveraging the technically superior 3.4L V6 74-degree architecture, the Evinrude 225HP H225HWLF is a High Output (H.O.) powerhouse with 3441cc displacement. Configured with a 20-inch shaft and integrated iSteer Dynamic Power Steering (DPS), this engine is engineered for high-performance bass boats and technical skiffs requiring maximum maneuverability. The G2 architecture focuses on torque density and structural soul, providing explosive hole-shots and a superior power-to-weight ratio for the US market.
Refined for efficiency, the H225HWLF utilizes PurePower direct injection to optimize the air-fuel mixture, reducing fuel-burn while maintaining dependable ignition. Ownership is simplified by the 5-year/500-hour maintenance schedule and zero-break-in requirement. This model features a premium white finish and integrated iTrim technology to automatically optimize engine angles for peak performance, ensuring a secure and responsive driving experience in various marine environments.
Key Features of Evinrude H225HWLF
- 3441cc V6 74-Degree Direct Injection.
- 225 Horsepower H.O. Prop Shaft Rating.
- 20-Inch Shaft 528 lbs Weight.
- E-TEC G2 3.4L High-Torque Induction.
- Integrated iSteer Dynamic Power Steering.
- 133 Amp Total Output Magneto.
- 1.85:1 Ratio Performance Gearcase.
Evinrude 225HP H225HWLF Specs
| Brand | Evinrude |
| Full Model Code | H225HWLF |
| Country of Origin | USA |
| Engine Family/Series | E-TEC G2 H.O. (Classic White) |
| Engine Type | V6 74° E-TEC Direct Injection |
| Displacement | 3.4 Liters |
| Horsepower | 225 HP |
| Full Throttle RPM Range | 5400-6000 RPM |
| Fuel Induction System | E-TEC Direct Injection w/ Stratified Low RPM Mode |
| Alternator Output | 133 Amps Total (50 Net Dedicated) |
| Gear Ratio | 1.85:1 |
| Shaft Length | L (20 inch) |
| Dry Weight | 244 kg |
| Bore x Stroke | 98 x 76 mm |
| Starting & Steering System | Electric / Integrated Dynamic Power Steering (iDPS) |
| Trim/Tilt Method | Power Trim and Tilt (i-Trim Included) |
| Oil Capacity | On-Engine 11.4 L |
| Recommended Fuel | 87 Octane |
| Standard Warranty | 5-Year Limited |
| Application | Tournament Bass Boats, Multi-Species Performance 20-22ft |
